經過不斷的驗證、改進再驗證、再改進，仿威圖機柜的功能也在不斷的完善，在其他領域的科技升級和創新，也不斷的融入到仿威圖機柜的生產技術中。那么仿威圖機柜都有哪些保護功能？

　　After continuous verification, improvement and verification, and improvement, the function of the imitation Weitu cabinet is also constantly improved, in other fields of science and technology upgrading and innovation, but also constantly into the production technology of the imitation Weitu cabinet. So what are the security protection functions of the imitation Weichart cabinet?

　　低壓斷路器保護功能：低壓斷路器在電路中除起控制作用外，還具有一定的保護功能，如過負荷、短路、欠壓和漏電保護等。

　　Low voltage circuit breaker protection function: low voltage circuit breaker in the circuit in addition to play a control role, but also has a certain protection function, such as overload, short circuit, undervoltage and leakage protection.

　　短路保護：由內部螺旋狀導體和銜鐵組成；過載過流保護：由雙金屬片和機械脫扣裝置構成；失壓保護：由失壓線圈，銜鐵和機械脫扣裝置組成。

　　Short circuit protection: composed of internal spiral conductor and armature; Overload and overcurrent protection: composed of bimetal sheet and mechanical release device; Loss of pressure protection: it is composed of loss of pressure coil, armature and mechanical release device.

　　隔離開關保護功能

　　Isolation switch protection function

　　維護人員的人身：在電氣設備檢修時，提供一個電氣間隔，并且是一個明顯可見的斷開點，用以保障維護人員的人身。

　　Safety of maintenance personnel: During the maintenance of electrical equipment, an electrical separation is provided and a visible disconnect point is used to ensure the personal safety of maintenance personnel.

　　短路保護功能：負荷開關具有在非故障條件下，接通或分?jǐn)嘭?fù)荷電流的能力和一定的短路保護功能。

　　Short circuit protection function: load switch has the ability of connecting or breaking load current and certain short circuit protection function under non-fault conditions.

　　總線保護作用：斷路器在斷開位置，只能先合母線側隔離刀閘，才能合線路側隔離刀閘。此種接線不僅防止帶負荷拉、合隔離開關，而且能防止違反開關、刀閘操作原則的違規操作。

　　Bus safety protection: in the open position of the circuit breaker, only the isolation switch on the bus side can be closed before the isolation switch on the line side. This kind of connection not only prevents pulling and closing the disconnecting switch with load, but also prevents illegal operation in violation of the operating principles of switch and switch.

　　負荷開關保護功能

　　Load switch protection function

　　一般裝有簡單的滅弧裝置，但其結構比較簡單。其工作過程是：分閘時，在分閘彈簧的作用下，主軸順時針旋轉，一方面通過曲柄滑塊機構使活塞向上移動，將氣體壓縮；另一方面通過兩套四連桿機構組成的傳動系統，使主閘刀先打開，然后推動滅弧閘刀使弧觸頭打開，氣缸中的壓縮空氣通過噴口吹滅電弧。

　　Generally equipped with a simple arc extinguishing device, but its structure is relatively simple. The picture shows a pneumatic high-pressure load switch, its working process is: when the brake, under the action of the brake spring, the main shaft rotates clockwise, on the one hand, through the crank slider mechanism to move up the piston, the gas compression; On the other hand, through the transmission system composed of two sets of four-link mechanism, make the main knife open first, and then push the arc extinguishing knife to open the arc contact, the compressed air in the cylinder through the nozzle to blow out the arc.

　　仿威圖機柜的保護功能并非某一個部件單一存在的，而是很多部件相互協同，有些部件具備相同或者相似的保護作用，兩種部件結合起來，就又增加了一道保護的保險。更多內容來此www.143318.com咨詢吧！

　　The security protection function of the imitation Vito cabinet is not a single component, but many components cooperate with each other. Some components have the same or similar protection effect. The combination of the two components adds a safety protection insurance. More content to this www.143318.com consultation!
